3/4" Water Butt Set with In-Line Tap, 20mm Barb Connector & Drill Bit

WBEX34MF-KIT013+DB

This kit includes:

• 1 x 3/4" BSP Water Butt Extension (EXTENSION34BSPM-F)
• 1 x Locking Nut (BUTT34BSPM-NUT)
• 2 x Sealing Washers (BUTT34BSPM-WASHER)
• 1 x In-Line Valve 3/4" BSP (HCV34BSPM001BLACK)
• 1 x 20mm Pipe Joiner with 3/4" BSP Female Thread (STR20B34BSPF)
• 1 x 27mm HSS Hole Saw Drill Bit (DB27MM)

The water butt extension connector is designed to increase the practicality of your rainwater collection system. With a 3/4" BSP male thread on one side and a female thread on the other, it provides a 50mm outward extension, perfect for attaching hoses or filling containers with greater ease.

Suitable for use with 26mm holes, the extension fitting can be quickly installed by screwing it into existing threads on your tank. If your water butt doesn’t have a pre-cut hole, use the included hole saw to create one in the ideal position.

Once installed, the extension creates more clearance for accessing stored water, making it easier to connect accessories and improving the overall convenience of your system.

The locking nut and sealing washers included in the set ensure the fitting stays firmly in place, even under water pressure. These components are made from robust materials for long-lasting performance and can be installed or removed easily.

The washers help spread tightening force evenly and create a watertight seal to prevent leaks—essential for efficient water management.

The 3/4" BSP In-Line Soft Touch Valve enables reliable and precise control of water flow. Its BSP male inlets and outlets allow for easy integration with standard plumbing systems. The valve is made from strong, lightweight plastic that resists wear, corrosion, and build-up.

Its smooth-turn mechanism and soft-touch grip make it user-friendly and suitable for frequent use. When shut, the valve creates a secure seal to prevent dripping or backflow, supporting consistent system performance.

Designed for low maintenance and long-term use, this valve is ideal for both home and commercial installations where efficient water control is required.

The 20mm Pipe Joiner with 3/4" BSP Female Thread is a high-quality connector ideal for irrigation systems. It combines a barbed end for 20mm pipe with a standard BSP female thread, offering a dependable connection point between irrigation pipework and accessories like in-line valves.

Manufactured from strong plastic, this joiner is weather-resistant and built to endure regular use. The barbed end ensures a tight, secure grip inside the pipe without requiring additional tools—just push and fit. Its simple design is perfect for repairs or extensions in drip systems and other irrigation setups.

The 27mm HSS Hole Saw Drill Bit is a precise and efficient cutting tool suitable for a wide range of materials, including metal, wood, and plastic. The high-speed steel build resists heat and wear, ensuring a long service life and consistent performance.

This drill bit is perfect for creating 3/4" BSP-sized openings, especially when installing water butt fittings. With a sharp, evenly spaced tooth pattern and a stable construction, it produces smooth, clean holes with minimal vibration—ideal for both professionals and DIYers.

Note: PTFE Tape is not included in this set and must be purchased separately.
